| Detection method |
On the radio |
Retro-reflective |
Diffuse reflection type |
| Project |
NPN output |
E3F3-T11 |
E3F3-R11 |
E3F3-R12 |
E3F3-D11 |
E3F3-D12 |
| E3F3-T16 |
E3F3-R16 |
E3F3-R17 |
E3F3-D16 |
E3F3-D17 |
| E3F3-T61 |
E3F3-R61 |
E3F3-R62 |
E3F3-D61 |
E3F3-D62 |
| E3F3-T66 |
E3F3-R66 |
E3F3-R67 |
E3F3-D66 |
E3F3-D67 |
| PNP output |
E3F3-T31 |
E3F3-R31 |
E3F3-R32 |
E3F3-D31 |
E3F3-D32 |
| E3F3-T36 |
E3F3-R36 |
E3F3-R37 |
E3F3-D36 |
E3F3-D37 |
| E3F3-T81 |
E3F3-T81 |
E3F3-T82 |
E3F3-T81 |
E3F3-T82 |
| E3F3-T86 |
E3F3-T86 |
E3F3-T87 |
E3F3-T86 |
E3F3-T87 |
| Detection distance |
5M |
3M ( no M.S.R function ) |
2M ( there M.S.R function ) |
0.1M |
0.3M |
| ( When using the E39-R1) |
( When using the E39-R1) |
| Standard sensing object |
Opaque objects : 11mm min |
Opaque objects : 56mm min |
100 × 100mm white drawing paper |
| Hysteresis |
- |
20% below the detection distance |
| A light source ( wavelength ) |
Infrared LED |
Red LED |
Infrared LED |
| Supply Voltage |
DC 12 ~ 24V 10% (p-p) 10% or less |
| Current consumption |
DC: 45mA Max |
DC: 25mA Max |
| Control Output |
Load power supply voltage DC26.4V less load supply current 100mA or less ( residual voltage of 1V or less ) |
| Protection circuit |
Reverse supply polarity / output short circuit |
| Response time |
Action / reply each 1.0ms or less |
| Sensitivity adjustment |
No |
Have |
| Ambient lighting |
Incandescent 3000lx less / less daylight 10000lx |
| Ambient temperature |
Action : -25 ~ +55 (with no icing) to save time : -30 ~ +70 (with no icing) |
| Humidity |
When the action : 45% ~ 85% (with no icing) when RH save : 35% ~ 95% (with no icing) RH |
| Insulation Resistance |
20M or more (500VDC) |
| Dielectric strength |
When more than AC1000V 50/60Hz, up between current-carrying parts and the housing 1 minute |
| Vibration resistance ( durability ) |
10 ~ 55Hz, 1.5mm double amplitude , reaching 1h in X, Y, Z direction |
| Impact resistance ( durability ) |
500m/s2 double the rate in the X, Y, Z directions 3 times each |
| Protection structure |
IEC60529 IP66 |
| Connection |
Wired ( standard cable length : 2m) / M12 connector |
| Indicator |
Operation indicator ( orange ) [ emitter power indicator ( orange ) ] |
| Weight |
Wire type |
Metal shell : 200gMAX |
Metal shell : 100g MAX |
| Plastic shell : 170g MAX |
Plastic shell : 85g MAX |
| Connector Type |
Metal shell : 120g MAX |
Metal shell : 60g MAX |
| Plastic shell : 40g MAX |
Plastic shell : 20g MAX |
| Packing |
Nylon |
| Material |
Shell |
ABS or BRASS |
| Shot |
PMMA |
| Attachment |
Nut : ABS or BRASS |
| Attachment |
Nuts ( 4 ) ; manual |
Reflector ; specification |
Nut ( 2 ) ; manual |
